Practical Electronics No 12 2023

Read in the issue 12 Practical Electronics 2023

Digital Boost Regulator by Tim Blythman. This board lets you use a PIC18F18146 8-bit microcontroller for any task while its onboard peripherals generate an adjustable voltage without interfering with what it’s doing. It includes capacitive sense buttons and a seven-segment display.
Dual-Channel Power Supply for Breadboards by Tim Blythman. This Dual-Channel Breadboard PSU plugs straight into a breadboard’s power rails, has two adjustable current-limited outputs and can run from different power sources.
Display Adaptor for the Breadboard PSU by Tim Blythman. This Display Adaptor attaches to the Breadboard PSU and displays lots of handy data, such as the set and actual voltages and currents.

Practical Electronics Magazine is the No. 1 UK magazine for hobby electronics enthusiasts everywhere. Each month’s issue is packed with practical constructional projects for the hobbyist, special features, advice and adverts from specialist electronics suppliers and more besides.

Contents:
